1panel部署IPFS网关(Kubo)
服务器部署IPFS网关教程
建议服务器配置在2C4G以上
在 1Panel 中的操作步骤:
步骤 1: 确认 setup_and_run.sh
脚本已创建并有执行权限
在 /opt/1panel/docker/compose/ipfs/
目录下创建了 setup_and_run.sh
文件,并且通过 1Panel 的文件管理给它设置了执行权限(例如 755
)。脚本内容如下:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
#!/bin/sh
# 适用于纯 IPv4 服务器的 IPFS setup_and_run.sh 脚本 (端口修改版)
# Check if the repo is initialized, if not, initialize it
if [ ! -f /data/ipfs/config ]; then
echo "IPFS repository not found, initializing..."
# 使用 server profile 优化,适用于服务器环境
ipfs init --profile=server
echo "IPFS repository initialized."
else
echo "IPFS repository found, skipping initialization."
fi
# Configure API and Gateway addresses to listen on all IPv4 interfaces with new ports
echo "Configuring IPFS API and Gateway addresses (IPv4) with new ports..."
# 监听所有 IPv4 地址的 11114 端口 (API)
# !!! 移除 --json 标志,并修改端口为 11114 !!!
ipfs config Addresses.API /ip4/0.0.0.0/tcp/11114
# 监听所有 IPv4 地址的 11104 端口 (Gateway)
# !!! 移除 --json 标志,并修改端口为 11104 !!!
ipfs config Addresses.Gateway /ip4/0.0.0.0/tcp/11104
echo "API and Gateway addresses configured with new ports."
# Configure Swarm addresses to listen on all IPv4 interfaces (port 4001 remains)
echo "Configuring IPFS Swarm addresses (IPv4)..."
# 监听所有 IPv4 地址的 4001 端口 (TCP 和 QUIC/UDP)
# Swarm 地址是一个数组,所以这里需要 --json
ipfs config Addresses.Swarm '["/ip4/0.0.0.0/tcp/4001", "/ip4/0.0.0.0/udp/4001/quic", "/ip4/0.0.0.0/udp/4001/quic-v1"]' --json
echo "Swarm addresses configured."
# !!! IMPORTANT: Announce your public IPv4 address for Swarm and new ports !!!
# Replace <YOUR_PUBLIC_IPV4> with your actual public IPv4 address
YOUR_PUBLIC_IPV4="<YOUR_PUBLIC_IPV4>" # <--- 在这里替换成你的公共 IPv4 地址
echo "Configuring IPFS Announce addresses (IPv4) with new ports..."
# 广告你的公共 IPv4 地址和 4001 (Swarm), 11114 (API), 11104 (Gateway) 端口
# Announce 地址是一个数组,所以这里需要 --json
ipfs config Addresses.Announce '["/ip4/'"$YOUR_PUBLIC_IPV4"'/tcp/4001", "/ip4/'"$YOUR_PUBLIC_IPV4"'/udp/4001/quic", "/ip4/'"$YOUR_PUBLIC_IPV4"'/udp/4001/quic-v1", "/ip4/'"$YOUR_PUBLIC_IPV4"'/tcp/11114", "/ip4/'"$YOUR_PUBLIC_IPV4"'/tcp/11104"]' --json
echo "Announce addresses configured with new ports."
# Configure CORS headers for the API
echo "Configuring CORS headers..."
# CORS headers 是 JSON 对象,所以这里需要 --json
# !!! 更新 CORS Origin 中的本地 API 端口 !!!
ipfs config --json API.HTTPHeaders.Access-Control-Allow-Origin '["https://ipfsbed.is-an.org","https://gw.ipfsbed.is-an.org", "http://localhost:3000", "http://127.0.0.1:11114", "https://webui.ipfs.io"]'
# 允许前端使用的 HTTP 方法
ipfs config --json API.HTTPHeaders.Access-Control-Allow-Methods '["PUT", "POST", "GET"]'
# 允许携带认证信息 (如果需要的话,这里前端代码似乎不需要)
ipfs config --json API.HTTPHeaders.Access-Control-Allow-Credentials '["true"]'
echo "CORS headers configured."
# Execute the main command: start the IPFS daemon
echo "Starting IPFS daemon..."
# 使用 'exec' 确保信号 (如停止) 正确传递给守护进程
exec ipfs daemon --enable-gc --enable-pubsub-experiment
如果你是ipv6服务器:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
#!/bin/sh
# 适用于纯 IPv6 服务器的 IPFS setup_and_run.sh 脚本 (Host Network Mode)
# Check if the repo is initialized, if not, initialize it
if [ ! -f /data/ipfs/config ]; then
echo "IPFS repository not found, initializing..."
# 使用 server profile 优化,适用于服务器环境
ipfs init --profile=server
echo "IPFS repository initialized."
else
echo "IPFS repository found, skipping initialization."
fi
# Configure API and Gateway addresses to listen on all interfaces (IPv6 only)
echo "Configuring IPFS API and Gateway addresses (IPv6 only)..."
# 监听所有 IPv6 地址的 5001 端口 (API)
ipfs config Addresses.API '["/ip6/::/tcp/5001"]' --json
# 监听所有 IPv6 地址的 8080 端口 (Gateway)
ipfs config Addresses.Gateway '["/ip6/::/tcp/8080"]' --json
echo "API and Gateway addresses configured."
# Swarm addresses are set via IPFS_LISTEN environment variable in docker-compose.yaml in host mode
# No changes needed here, as IPFS_LISTEN will handle :: and your announced address will be specific.
# !!! IMPORTANT: Announce your public IPv6 address for Swarm !!!
# Replace <YOUR_PUBLIC_IPV6> with your actual public IPv6 address
YOUR_PUBLIC_IPV6="<YOUR_PUBLIC_IPV6>" # <--- 已经帮你填入你的公共 IPv6 地址
echo "Configuring IPFS Announce addresses (IPv6)..."
# 广告你的公共 IPv6 地址和 4001 端口 (TCP 和 QUIC/UDP)
# Announce 地址是一个数组,所以这里需要 --json
ipfs config Addresses.Announce '["/ip6/'"$YOUR_PUBLIC_IPV6"'/tcp/4001", "/ip6/'"$YOUR_PUBLIC_IPV6"'/udp/4001/quic", "/ip6/'"$YOUR_PUBLIC_IPV6"'/udp/4001/quic-v1"]' --json
echo "Announce addresses configured."
# Configure CORS headers for the API
echo "Configuring CORS headers..."
# CORS headers 是 JSON 对象,所以这里需要 --json
ipfs config --json API.HTTPHeaders.Access-Control-Allow-Origin '["*"]'
ipfs config --json API.HTTPHeaders.Access-Control-Allow-Methods '["PUT", "POST", "GET"]'
ipfs config --json API.HTTPHeaders.Access-Control-Allow-Credentials '["true"]'
echo "CORS headers configured."
# Execute the main command: start the IPFS daemon
echo "Starting IPFS daemon..."
# Use 'exec' to ensure signals are passed correctly
exec ipfs daemon --enable-gc --enable-pubsub-experiment # Add any other flags you need
步骤 2: 在 1Panel 中修改 IPFS Docker Compose 配置
我们将修改之前创建的 Compose 配置,而不是重新创建。
- 登录你的 1Panel 面板。
- 导航到左侧菜单的 容器 -> Compose。
- 找到你之前创建的
ipfs
Compose 项目,点击右侧的 编辑 按钮。 -
在 Compose 内容文本框中,将现有的 YAML 内容替换为以下内容。主要变化是移除了
command
,并添加了entrypoint
。1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37
version: '3.8' services: ipfs: image: ipfs/go-ipfs:latest # 使用最新的 go-ipfs 镜像 container_name: ipfs_node restart: unless-stopped # 容器退出时自动重启 networks: - ipfs_network # 使用一个自定义网络 ports: # Swarm port - IPFS P2P 通信端口 (通常保持 4001) - "4001:4001" # API port - 用于与 IPFS 节点交互,前端上传将用到此端口 - "11114:11114" # Gateway port - 用于通过 HTTP 访问 IPFS 内容 - "11104:11104" volumes: # 持久化存储 IPFS 数据到宿主机 /opt 目录下的子目录 - /opt/ipfs_staging:/export # 临时存储区域 - /opt/ipfs_data:/data/ipfs # IPFS 仓库数据 # 挂载 setup_and_run.sh 脚本到容器内部,并设置为只读 # 宿主机路径: /opt/1panel/docker/compose/ipfs/setup_and_run.sh # 容器内部路径: /opt/setup_and_run.sh - /opt/1panel/docker/compose/ipfs/setup_and_run.sh:/opt/setup_and_run.sh:ro # 覆盖镜像的默认 ENTRYPOINT,直接执行我们的脚本 entrypoint: /opt/setup_and_run.sh networks: ipfs_network: driver: bridge # 使用桥接网络 # volumes: # Omitted as we are using host paths # ipfs_staging: # ipfs_data:
如果你是ipv6:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
version: '3.8'
services:
ipfs:
image: ipfs/go-ipfs:latest # 使用最新的 go-ipfs 镜像
container_name: ipfs_node
restart: unless-stopped # 容器退出时自动重启
# !!! 修改网络模式为 host !!!
network_mode: host
# !!! 移除 ports 部分,因为在 host 模式下端口直接在宿主机上监听 !!!
# ports:
# - "4001:4001"
# - "5001:5001"
# - "8080:8080"
volumes:
# 持久化存储 IPFS 数据到宿主机 /opt 目录下的子目录
- /opt/ipfs_staging:/export # 临时存储区域
- /opt/ipfs_data:/data/ipfs # IPFS 仓库数据
# 挂载 setup_and_run.sh 脚本到容器内部,并设置为只读
# 宿主机路径: /opt/1panel/docker/compose/ipfs/setup_and_run.sh
# 容器内部路径: /opt/setup_and_run.sh
- /opt/1panel/docker/compose/ipfs/setup_and_run.sh:/opt/setup_and_run.sh:ro
# 覆盖镜像的默认 ENTRYPOINT,直接执行我们的脚本
entrypoint: /opt/setup_and_run.sh
# 移除 command,因为 entrypoint 已经指定了要执行的命令
# 添加环境变量 (保留这个,可能有助于Go的网络行为)
environment:
- IP_SOCKET_VFLAGS=IPV6_V6ONLY=0
# IPFS_LISTEN 环境变量在 host 模式下,对于纯 IPv6 环境,只保留 IPv6 监听
- IPFS_LISTEN=/ip6/::/tcp/4001,/ip6/::/udp/4001/quic-v1
# !!! 移除 networks 定义,因为服务使用 host 网络模式 !!!
# networks:
# ipfs_network:
# driver: bridge
# enable_ipv6: true
# volumes: # Omitted as we are using host paths
# ipfs_staging:
# ipfs_data:
- 点击编辑器右上角的 保存 按钮。
- 保存成功后,在 Compose 列表中找到
ipfs
,点击右侧的 重新部署 按钮。 - 等待重新部署完成。点击 日志 查看容器启动情况。这次你应该能看到脚本中的
echo
输出,并且 IPFS 守护进程应该能正常启动。
步骤 3, 4, 5: 配置反向代理、创建静态网站、修改前端代码
分别反代 5001、8080 端口
步骤 6: 测试
